4-axis Mazak HCN 4000 ( 2018 )

This 4-axis Mazak HCN 4000 was manufactured in 2018 and features a Mazatrol SmoothG control, through-spindle cooling at 32 bar, and a Renishaw OMP 60 touch probe. With a spindle speed of up to 18,000 rpm and a tool magazine capacity of 60, it's ideal for precise and efficient machining. Consider the opportunity to buy this Mazak HCN 4000 horizontal machining centre. Contact us for more information about this machine.

Control Unit

• Control Brand: MAZATROL
• Control Model: SmoothG

Movement

• Number of Axes: 4
• X-axis Travel: 560 mm
• Y-axis Travel: 640 mm
• Z-axis Travel: 640 mm

Technical Specification

• Number of Tools: 60
• Spindle Power: 35 kW
• Spindle Speed: 18000 RPM
• Taper Size: SK 40

• Table: Pallet size 400 x 400 mm; Number of pallets 2; Indexing 1° increments

• Control: Mazatrol SmoothG

• Coolant/air: Through-spindle cooling 32 bar; Through-spindle air supply; Niagara flushing

• Functions: Tapping without compensating chuck (rigid tapping); G00 tilt function

• Compliance: CE marking

Additional equipment

• Renishaw OMP 60 touch probe

• Renishaw Inspection+ (Version 2022)

• Tool length measurement system

• Tool ID system

• Chip conveyor

• Additional filter cartridges
