Engel VICTORY 200/80 Power

VICTORY 200/80 Power

SN:50294

Year:2006

Closing force (kN) 800

S10 screw, diameter 30mm

Working hours: ONLY 4.500

Mounting plates enlarged vertically

Mould  heater with 12 control loops

Version HV 2 with control pumps (pressure and flow control in a closed control loop)

for parallel movement sequence

Microcomputer CC100 A03

Ethernet interface for use with EMS

8x digital output, 8x digital input

Interface for ejector protection

Interface for temperature control units Data protocol Engel, physical type: 20MA-CL

Microflow

MINI-CAM Process parameter adjustment support based on an expert system

2-pole service socket, 230V

6x 3-phase socket, 10A / 16A

2x 3-phase socket, 10A / 16A, switchable

2/2-way magnetic air valve, R1/4 inch

Flow regulator 0-10 l, 4 circuits

Temperature control circuits can be switched off manually or automatically (centrally at the flow controller) - Switch-off function selectable.

Tubing for flow controller, 4 temperature control circuits
